Install Odoo with Apache Reverse Proxy







Sponsored

If you see any prompts during system update, enter y.

2. Install PostgreSQL Server

Odoo uses PostgreSQL server to store its information, so we will install PostgreSQL with the following command.

$ sudo apt install postgresql

After installation, PostgreSQL will start automatically, and also be enabled for auto-start on system reboot.

3. Install Odoo

There are two ways to install Odoo. We will look at both these methods.

Method 1

If you are performing a fresh installation of Odoo on your system, you can use these steps.

Since Odoo is not available in official Ubuntu Repository, we need to add its repository and download it using the following commands.

$ sudo wget -O - https://nightly.odoo.com/odoo.key | apt-key add -
$ sudo echo "deb http://nightly.odoo.com/12.0/nightly/deb/ ./" >> /etc/apt/sources.list.d/odoo.list

Next, update local package database.

$ sudo apt update

Install Odoo with the following command.

$ sudo apt install odoo

This command will automatically install/update python, create PostgreSQL user and create Odoo instance on your system.

After installation is complete, you can check Odoo’s status with the following command.

$ sudo systemctl status odoo

Method 2

If you want to maintain multiple Odoo versions on your system, or you already have Odoo installed on your system, you can follow these steps.

In this case, we install Odoo from its github repository using python virtual environment.

Run the following command to install pre-requisites.

$ sudo apt install build-essential wget git python3-pip python3-dev python3-venv python3-wheel python3-setuptools libxslt-dev libzip-dev libldap2-dev libsasl2-dev python3-setuptools node-less

Create a new system user with the following command.

$ sudo useradd -m -d /opt/odoo12 -U -r -s /bin/bash odoo12

Next, create a new PostrgeSQL user.

$ su - postgres -c "createuser -s odoo12"

In this case, we will also need to install Wkhtmltopdf to allow Odoo to export PDF reports. Since Odoo requires version Wkhtmltopdf 0.12 which is not available in Ubuntu repositories, you need to add the repository and then install it.

$ cd /opt
$ sudo wget https://builds.wkhtmltopdf.org/0.12.1.3/wkhtmltox_0.12.1.3-1~bionic_amd64.deb
$ sudo apt install /opt/wkhtmltox_0.12.1.3-1~bionic_amd64.deb

Next, install Odoo. First we switch to the newly created system user.

su - odoo12

Run the following command to clone Odoo’s git repository.

$ sudo git clone https://www.github.com/odoo/odoo --depth 1 --branch 12.0 /opt/odoo12/odoo

Let’s also create python virtual environment and activate it.

$ sudo python3 -m venv odoo-venv
$ sudo source odoo-venv/bin/activate
$ pip3 install wheel
$ pip3 install -r odoo/requirements.txt
(venv) $ deactivate && exit

Next, we create a configuration file for Odoo.

$ sudo cp /opt/odoo12/odoo/debian/odoo.conf /etc/odoo12.conf

Open configuration file with a text editor.

$ sudo vi /etc/odoo12.conf

Add the following lines. Replace admin123 with password of your choice.

[options]
; This is the password that allows database operations:
admin_passwd = admin123
db_host = False
db_port = False
db_user = odoo12
db_password = False
addons_path = /opt/odoo12/odoo/addons
xmlrpc_port = 8001

Save and close the file. Next, we create a system file to manage Odoo.

$ sudo vi /etc/systemd/system/odoo12.service

Add the following lines to it.

[Unit]
Description=Odoo12
Requires=postgresql.service
After=network.target postgresql.service

[Service]
Type=simple
SyslogIdentifier=odoo12
PermissionsStartOnly=true
User=odoo12
Group=odoo12
ExecStart=/opt/odoo12/odoo-venv/bin/python3 /opt/odoo12/odoo/odoo-bin -c /etc/odoo12.conf
StandardOutput=journal+console

[Install]
WantedBy=multi-user.target

Save and close the file. Restart Odoo to apply changes.

$ systemctl daemon-reload
$ systemctl start odoo12

4. Setup Apache as Reverse Proxy

Next, we install and enable Apache server with the following commands.

$ sudo apt install apache2
$ sudo systemctl enable apache2

You can verify that Apache server works, by opening web browser and visiting http://127.0.0.1. It will show you the message ‘It works!’

Next, run the following commands to install HTTP proxy module.

$ sudo a2enmod proxy
$ sudo a2enmod proxy_http

Now create a new virtual host file for your domain example.com.

$ sudo vi /etc/apache2/sites-available/example.com.conf

Add the following lines to it. Replace example.com with the your domain name.

ServerName example.com
ServerAlias www.example.com

ProxyRequests Off

Order deny,allow
Allow from all


ProxyPass / http://example.com:8069/
ProxyPassReverse / http://example.com:8069/

Order allow,deny
Allow from all

Save and close the file. The above configuration makes Apache accept requests sent to domain example.com and send them to port 8069, the default port for Odoo.

Enable the virtual configuration file.

$ sudo a2ensite example.com

Restart Apache server to apply changes.

$ sudo service apache2 restart

Now when you open browser and visit http://example.com you will see the Odoo login screen.

Enter the required details such as Odoo admin password, database name, etc. and proceed to start using Odoo.

In this article, we have learnt how to install and configure Apache reverse proxy for Odoo. If you want to run Odoo over HTTPS/SSL then just configure SSL certificate for your Apache server, as per the steps mentioned here.
